KVM Rackmount Console Kit (18.5)

High-Performance 1U KVM Console Kit 18.5″

Combining an HD 18.5″ LCD monitor with keyboard and touchpad in a dense lightweight 1U form factor, the UPtyma KVM Console Kit allows you easily accessible control in 1U of rack space. You have the option of connecting the console to either a single system or a multi-port KVM switch to manage multiple systems. Worldwide TAA compliant, our KVM Rackmount Console Kit supports VGA and Display Port inputs.

Product Features

  • 18.5-inch Screen
  • HD Flat Panel LCD
  • Low profile keyboard with integrated number pad
  • Multi-port KVM switch can be mounted behind in the
    same 1U of space
  • Includes a three-button Capacitive Touchpad
  • TAA (Made in USA) compliant version available
  • Variety of keyboard languages available upon request (UK, DE, FR, RU, JP, INTL, LA/ES, US, INDIA)
  • OSD Language Support (English, French, German, Japanese, Simple Chinese and Spanish)
  • Toolless rails for rack installation are included with each console kit allowing for quick installation
  • Supports video resolutions from 640 x 480 through 1680 x 1050 at 60 and 75 Hz refresh rates
  • Maximum Resolution 1680 x 1050

Technical Specs for KVM Rackmount Console Kit 18.5"

Physical Dimensions
H x W x D
1.66 × 17.17 × 17.05 inches (4.23 × 43.61 × 43.3 cm)
Weight
11.43 lbs (5.2 kg)
Display
Type
Flat-panel, active matrix-TFT LCD with anti-glare coating
Display
18.5 in (46.99 cm), 16:10 aspect ratio
Viewable (diagonal)
18.51 in digital display (47.02 cm) 16:10 aspect ratio
Maximum Input Graphics Resolution
1680 x 1050 @ 60 Hz
Response Time
<16ms
Brightness
>187 (cd/m^2)
Contrast Ratio
> 700:1
Keys
101, 102, or 106 layout (depending on country) including inverted T scroll keys, Windows keys
Environmental Temperature
Operating
0º to 50º C (32º to 122º F)
Non-operating
-30º to 60º C (-22º to 140º F)
Storage Temperature
-20° to 60°C (-4° to 140°F)
Humidity (non-condensing)
Operating
10% to 90%
Storage
10% to 90%
Power Source
Source
90 to 264 VAC, 47 to 63 Hz
Maximum Power Consumption
<36W
Altitude
Operating
0 to 10,000 ft (0 to 3048 m)
Non-operating
0 to 30,000 ft (0 to 9144 m)
Supported Graphics Mode (Output)
Mode
640 x 480 VGA through 1680 x 1050 WXGA+60, and 75 Hz refresh rates
Keyboard/Mouse Output
USB 2.0 connector
OSD Language Selection
English, Spanish, French, German, Italian, Japanese, Simplified Chinese

Available Models

  • 18.5 1U RM Console – TAA
 AB200A
  • 18.5 1U RM Console – UK
 AB201A
  • 18.5 1U RM Console – DE
 AB202A
  • 18.5 1U RM Console – FR
 AB203A
  • 18.5 1U RM Console – IT
 AB204A
  • 18.5 1U RM Console – ES
 AB205A
  • 18.5 1U RM Console – DK
 AB206A
  • 18.5 1U RM Console – NO
 AB207A
  • 18.5 1U RM Console – SE/FI
 AB208A
  • 18.5 1U RM Console – CH
 AB209A
  • 18.5 1U RM Console – PT
 AB210A
  • 18.5 1U RM Console – BE
 AB211A
  • 18.5 1U RM Console – RU
 AB212A
  • 18.5 1U RM Console – JPN
 AB213A
  • 18.5 1U RM Console – INTL
 AB214A
  • 18.5 1U RM Console – LA/ES
 AB215A
  • 18.5 1U RM Console – CA
 AB216A
  • 18.5 1U RM Console – NL
 AB217A
  • 18.5 1U RM Console – US
 AB218A
  • 18.5 1U RM Console – KR
 AB219A
  • 18.5 1U RM Console – CN
 AB220A
  • 18.5 1U RM Console Only – TAA
 AB221A

Product Documents

  • UPtyma 185RM18A 18.5 QuickSpec English Download
  • UPtyma 185RM18A 18.5 User Guide English Download
  • UPtyma 185RM18A 18.5 User Guide Spanish Download
  • UPtyma 185RM18A 18.5 User Guide Chinese Download
  • UPtyma 185RM18A Uptyma Inner Rail Installation Download
